Sturdy steel shells for long life
Corrosion resistant epoxy powder paint fi nish
Maximum working pressure: 28bar
It is strongly recommended to assemble TDHR Series Cooling & He-ating Exchanger to the refrigeration system whose evapourtem-peraturelower phan-15℃
Products are compatible with HFCs, HCFCs, CFCs, as well as with their associated oils and additives
* WeChat is the same as your phone number, and you can also add WeChat for communication
The refrigeration line has high pressure and low pressure parts, high pressure refrigerant are with high temper-ature, which need condenser to cool down and obtain the low temperature And the low pressure gas should be separated of the gas and liquid refrigerants The liquid refrigerant will take time to rise the temperature, it should evaporateinto gas before entering into compressor.
The function of heat exchanger is to combine the high pressure & hioh temperature refrigerant and the low pres-sure & low temperature into one vessel ,to cool the hot refrigerant and heat up the cold refrigerant.After passes through the heat exchange function, the system efficiency will be able to achieve the best refrigeration effect.
Sturdy steel shells for long life
Corrosion resistant epoxy powder paint fi nish
Maximum working pressure:28bar
lt is strongly recommended to assemble TDHR Series Cooling &He-ating Exchanger to the refrigeration system whose evapourtem-peraturelower phan-15℃
Products are compatible with HFCs, HCFCs, CFCs, as well as with their associated oils and additives
